Limited access between lighting bridges #1, #2, and none available at #3. Points consist of graded steel eye-bolts protruding through ceiling directly above bridges. Rigging requires significant bridling to clear lighting bridges and ceiling baffles. F.O.H. rigging requires sufficient advance notice.
Carpentry
The house employs very strict safety guidelines involving rigging. All rigging is to be approved and or modified as necessary by the Master Carpenter/Rigger. Contact Master Carpenter/Rigger for specific stage rigging equipment requirements.
Fly Loft
The fly loft is available when acoustic ceiling panels aren't used (Lyric or Drama).
- Grid: suspended grid of 4"w channel iron with 1 15/16" slots and overhung loft blocks
- Grid height: 82' 0"
- Access to grid: staircase stage left, no elevator
- Loading bridges: + 42' level + 62' level + 77' level
- Counterweight locking rail position: stage left, + 0' (stage) level
- Pin rail position: stage left and right, + 42' level
Linesets
Linesets are available when overhead acoustic ceiling panels are not used (Lyric or Drama). Linesets are single-purchase counterweights.
- Total numbered linesets: 69, numbered 1 through 69 and includes:
- (2) motorized permanent electrics (#5 and #20)
- (2) sets of side tabs, 1-Drama, 1-Lyric
- Additional non-numbered linesets:
- (4) motorized side-lighting ladder sets
- 2 sets stage left, 2 sets stage right, 8 total
- (3) motorized concert ceiling panels
- (4) motorized side-lighting ladder sets
- Usable loading capacity per lineset:
- 2000 lbs. linesets #5 and #20 (motorized elecs)
- 400 lbs. linesets #64 and #65 (DS side tabs)
- 1400 lbs. all other linesets
- Arbor length: 8’
- Standard house brick weight: 23, 19, & 10 lbs.
- Total weight available: Approximately 53,110 lbs. (after balancing normal house equipment)
- Distance between linesets: Varies. See separate Lineset charts.
Number of Linesets, available by stage configurations:
| Configuration | Drama | Lyric | In-the-Round | Concert | Arena/Cabaret |
| Quantity Available | 39 | 44 | None | None | 1 |
| Linesets #'s | (See Drama Lineset Chart) | (See Lyric Lineset chart) | Concert ceiling in place | Concert ceiling in place | #65 |
Linesets and Plots
For additional lineset information, please contact the Operations Manager.
Rigging
Varies depending on stage configuration.
Points are available virtually anywhere in the fly loft (Lyric). Low-load points taken directly from the grid's channel iron using grid baskets or motor stands (6 in house). High-load points may be taken from the grid's overhung I-beams and requires bridling.
- Between the F.O.H. rigging points and the fly loft, approximately 19' wide upstage to downstage and spanning the entire width of the auditorium.
- In-The-Round Configuration, the no-rigging zone lies directly above the center of the stage. Lighting and sound truss running upstage to downstage must be able to span the no-rigging zone. Minimum truss length upstage to downstage is 20' (outside dimensions).
- In Arena, Cabaret, and Concert with ceiling panels above stage, rigging points downstage and midstage between panels or three (3) holes in the upstage panels. In Lyric & Drama, areas where ceiling panels pivot and store.
- Span sets, steel slings, shackles, spotting sheaves, hand line, and (17) one ton chain motors, (6) half ton chain motors, (6) 500lb chain motors, trussing sections and safety equipment available upon request.
- Not all motors are available at all times. In Arena and Concert only four one-ton motors are available as the rest are used for house set-up.
Please note that the following rigging points in the image are only for the arena configuration.
Stage Floor and Dimensions
The stage surface is a sealed, multi-layered epoxy product on top of a slightly sprung plywood subfloor. The stage cannot be drilled or lagged. Any damage to the stage surface will result in the company being charged for its repair.
- Arena Stage Dimensions: 36'd x 48'w
- Lyric Stage Dimensions: 45'd x 44'w
- Drama Stage Dimensions: 45'd x 42'w
- In-the-Round Stage Dimensions: 24'd x 24'w
Stage Equipment
Aluminum frame, black PVC surface. Full black masking supplied. The is max load is 200lb square feet.
- (85) Wenger versatile 4'x8' platform tops
- (8) Wenger versatile 4'x4' platform tops
- (4) Wenger Versatile 2'x8' platform tops
- (4) 3'x3' tri corners
- (4) 4'x4' tri corners
- (4) 2'x4' platform tops
- (2) 2'x2' platform tops
4’ x 8’ platforms require six (6) legs each, 4’ x 4’ require four (4) legs each.
- (233) 8" aluminum legs (38 platforms)
- (176) 16" aluminum legs (29 platforms)
- (207) 24" aluminum legs (34 platforms)
- (202) 32" aluminum legs (33 platforms)
- (390) 40" aluminum legs (65 platforms)
- (56) 24"/28"/32"/36" variable height legs
(6) Wenger 3 or 4 - step, 6' L choir risers can be set-up straight or in an arc. Wenger 4x8 risers can also be used for a deeper choir riser.
Harlequin reversible black/white 55' W x 40' L (6 rolls = 6’2" W x 55’ L)
Custom shell walls with integrated doors (6 sections, each: 12' 6" W x 16' H)
Two (2) available. Light ash, natural finish.
Pipe and Drape V2.0
Consisting of 2' square bases with telescoping uprights and telescoping horizontals, with pocketed duvytene panels that fit on the horizontal cross members. Typically used to mask off stage areas or erect quick-change booths. Each plate and has three mounting positions. Black only.
Drapes
Please note that soft goods are available in Lyric or Drama.
- Fire curtain: rigid, motor driven (available in Drama and Lyric configurations only). Requires the first 2’ downstage of the main
- Curtain must be clear at all times
- Main curtain: Red, manually fly in or out (available in Drama and Lyric configurations only)
Black Masking
| Quantity Borders | Width | Height | Fullness |
| 6 | 62' 0" | 15' 0" | Flat |
Legs
- 2 pair (4); 21' 0"; 30' 0"; Flat
- 2 pair (4); 15' 0"; 30' 0"; Flat
- 2 pair (4); 12' 0"; 30' 0"; Flat
Side Tabs
- 1 pair (2;) 36' 0"; 30' 0"; 50%
Orchestra
- (80) Music Stands
- (80) Music Stand Lights
- (140) Padded armless black chairs
- Conductor Podium & Stand
Lifts
- #1- Lift Aloft Man Lift; 25’ Platform height; Battery powered; Drivable
- #2- Genie; 1932 Scissor Lift; 25’ working height
- #2- Genie; 36' Platform height, battery powered (Must use outriggers and lower to move)
- #3- Genie; 24' Platform height, battery powered (Must use outriggers and lower to move)
